handhold electric

Handhold Electric Dot Peen Marking Machine

Our handheld electric dot peen marking machines are plug and play without compressed air supply in need, compared to pneumatic dot peen marking produces less metal dust splash and noise level, widely used in a variety of airless marking occasions, we also offer battery powered all-in-one models for customers’ field marking business.

The handheld electric dot peen marking machine is widely used in automobile body, sheet metal parts, nameplates, etc., marking accurately and quickly, especially for aluminum, copper and plating or anodized products surfaces are beautifully marked and easy to maintain, or field marking the gigantic workpieces such as installed gas and water pipeline.

Description

Technical Data of Our Handhold Electric Marking Machine

Choose from our standard machines below and slide to the right for more information, or contact us for a solution

Typical AppearanceMachine TypeWork AreaMarking SpeedMarking DepthControllerMarking Needle
electric pin marking1Handheld80*40~140*80mm1~5cps or 5~100mm/s0.1~0.3mm for single write on steel, 1mm max.Thorx6/Thorx7 PC-based controllerThorx6/Thorx7 PC-based controller
 electric pin marking3Handheld80*40~140*80mm1~5cps or 5~100mm/s0.1~0.3mm for single write on steel, 1mm max.Thorx6/Thorx7 touchscreen controller4mm for standard, or custom needles for specialized purposes.
 electric pin marking5All in one115*35mm1~5cps or 5~100mm/s0.1~0.3mm for single write on steel, 1mm max.Kingmark3 integrated touchscreen4mm for standard, or custom needles for specialized purposes.

Choose Control Software on Your Marking Demanding

Thorx-6 software are widely used in pin marking industry with suffice functions for English environment, however, if you need more language support, check the table for right one, or ask for advice.


Thorx-6
Thorx-7
Kingmark-3
Kingmark-8
UI LanguageEnglishEnglishAll languageAll language
Marking ContentEnglish fonts (letters & numbers), vector graphicsEnglish fonts & dot-fonts, vector graphics, Datamatrix (QR code)English fonts & dot-fonts, vector graphics, Datamatrix (QR code)All language fonts & dot-fonts, vector graphics, Datamatrix (QR code)
Font FormatSHX, SLF, TTF, SHP
Graphic FormatPLT, SLG, WMF, EMF, DWG, DXF
Controller ConfigurationTouchscreen controller or industrial PC controller with USB & RS232 connection.
Touchscreen Size7’’10.1’’

Marking Samples

electric marking sample2
electric marking sample3
electric marking sample4
electric marking sample5
electric marking sample6
electric marking sample7
electric marking sample8
electric marking sample1
Benchtop Pneumatic Dot Peen Engraver
Benchtop Pneumatic Dot Peen Engraver
Benchtop Pneumatic Dot Peen Engraver
Benchtop Pneumatic Dot Peen Engraver
Benchtop Pneumatic Dot Peen Engraver
Benchtop Pneumatic Dot Peen Engraver
Benchtop Pneumatic Dot Peen Engraver
Benchtop Pneumatic Dot Peen Engraver

Clients who chose our electric dot peen marking machines.

UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer
UV Laser Marking Machine Customer

FAQs about our handhold electric dot peen marking machines.

There is no price here because the price depends on laser type, brand, model, working area, optional appearance, and more. Also, the cost of a machine will be affected by currency, raw material sheets, technology iteration of the laser source, and galvanometer. Therefore, contact us to get the real-time price to save your dollars or pennies.

The final dimension and weight of the machine and shipping package are influenced by detailed configuration, including laser source brand and model, machine appearance, galvanometer brand and model, chiller for water cooling method machines, etc. We develop and manufacture single machinery for each client for specialized demands and we recommend configuration based on the factors of useability, maintenance, shipping, workshop space available,

For all machines, we provide 2 years of online, video & live chat technology support, and we configure priority components brands, which are available to provide domestic repair & replacement service of laser source faults to maximize the usability of our customers.

We manufacture every single machine according to the specialized order, the standard machines take no more than 8 working days, and lite customized machines usually take 10~15 working days. Then the delivery based on air or sea takes 5~60 days.

Want an un art handing video demonstration on specialized material? Looking for a solution to your specialized environment or automatic process demand?
